Technical data for the BMW M235 xDrive Gran Coupé.

¹
Powertrain type	Petrol – 48 Volt Mild-Hybrid
Power in kW (hp)	120 (163) ²
Torque in Nm	400 ²
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

¹
Cylinders	4
Displacement in cm3	1,995
Nominal power in kW (hp)/1/min	110 (150) / 3,750 - 4,000
Nominal torque in Nm/1/min	360 / 1,500 - 2,500


(Nominal) power/30 minutes power in kW (hp)	15 (20)/9
(Nominal) torque in Nm	55


Acceleration 0–100 km/h in s	8
Maximum speed in km/h	226

^{1 ,} ³
Fuel consumption, combined WLTP in l/100 km	4.6–4.2
CO2 emissions, combined WLTP in g/km	120–110
Stationary noise level in dB(A) / 1/min	65
Pass-by noise in dB(A)	76 / 3,000

⁴
Battery capacity in kWh	0.9


4,546 mm
1,800 mm
1,445 mm
Length in mm	4,546
Width in mm	1,800
Height in mm	1,445
Wheelbase in mm	2,670
Curb weight in kg ⁵	1,600
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁶	1,300 / 75
Luggage capacity in l	360
Fuel capacity in l	49

¹
Powertrain type	Petrol
Power in kW (hp)	115 (156)
Torque in Nm	230
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

¹
Cylinders	3
Displacement in cm3	1,499
Nominal power in kW (hp)/1/min	115 (156)/4,700–6,500
Nominal torque in Nm/1/min	230/1,500–4,400


Acceleration 0–100 km/h in s	8.6
Maximum speed in km/h	230

^{1 ,} ³
Fuel consumption, combined WLTP in l/100 km	6.3
CO2 emissions, combined WLTP in g/km	143
Stationary noise level in dB(A) / 1/min	67
Pass-by noise in dB(A)	78/3,750


4,546 mm
1,800 mm
1,445 mm
Length in mm	4,546
Width in mm	1,800
Height in mm	1,445
Wheelbase in mm	2,670
Curb weight in kg ⁵	1,420
Luggage capacity in l	430
Fuel capacity in l	49

¹
Powertrain type	Petrol
Power in kW (hp)	221 (300)
Torque in Nm	400
Transmission	7-speed, automatic
Drivetrain	All-wheel drive

¹
Cylinders	4
Displacement in cm3	1,998
Nominal power in kW (hp)/1/min	221 (300) / 5,750 - 6,500
Nominal torque in Nm/1/min	400 / 2,000 - 4,500


Acceleration 0–100 km/h in s	4.9
Maximum speed in km/h	250

^{1 ,} ³
Fuel consumption, combined WLTP in l/100 km	8.3
CO2 emissions, combined WLTP in g/km	185
Stationary noise level in dB(A) / 1/min	67
Pass-by noise in dB(A)	73 / 3,750


4,546 mm
1,800 mm
1,445 mm
Length in mm	4,546
Width in mm	1,800
Height in mm	1,445
Wheelbase in mm	2,670
Curb weight in kg ⁵	1,575
Luggage capacity in l	430
Fuel capacity in l	49

¹
Powertrain type	Petrol – 48 Volt Mild-Hybrid
Power in kW (hp)	125 (170) ²
Torque in Nm	280 ²
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

¹
Cylinders	3
Displacement in cm3	1,499
Nominal power in kW (hp)/1/min	115 (156) / 4,700 - 6,500
Nominal torque in Nm/1/min	240 / 1,500 - 4,400


(Nominal) power/30 minutes power in kW (hp)	15 (20)/9
(Nominal) torque in Nm	55


Acceleration 0–100 km/h in s	7.9
Maximum speed in km/h	230

^{1 ,} ³
Fuel consumption, combined WLTP in l/100 km	5.7–5.2
CO2 emissions, combined WLTP in g/km	119
Stationary noise level in dB(A) / 1/min	67
Pass-by noise in dB(A)	78 / 3,750

⁴
Battery capacity in kWh	0.9


4,546 mm
1,800 mm
1,445 mm
Length in mm	4,546
Width in mm	1,800
Height in mm	1,445
Wheelbase in mm	2,670
Curb weight in kg ⁵	1,525
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁶	1,300 / 75
Luggage capacity in l	360
Fuel capacity in l	49

1 Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.

2 Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value).

3 Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

4 The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

5 The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.

6 Trailer load depends on the vehicle options

Consumption and CO2 emissions.

BMW M235 xDrive Gran Coupe¹: Fuel consumption, combined WLTP in l/100 km: 8.3; CO2 emissions, combined WLTP in g/km: 185

All vehicles, equipment, combination possibilities and varieties shown here are examples and can differ in your country.
