BMW X1 technical data

BMW X1

BMW X1: TECHNICAL DATA

BMW X1BMW X1: TECHNICAL DATA

Here you can find the technical data of the BMW X1.

Read more

TECHNICAL DATA OF THE BMW X1.

Weight

Unladen weight EU in kg 1,495 [1,505]
Max. permissible weight in kg 2,000 [2,025]
Permitted load in kg 550 [550]
Permitted axle load front/rear in kg 990/1,035 [1,020/1,035]
Luggage capacity min. (seats up or roof down) in l 505 [505]
Luggage capacity max. (seats down or roof up) in l 1,550 [1,550]
Trailer load (unbraked) in kg 735 [740]
Trailer load 8% (braked) in kg 1,700 [1,700]
Trailer load 12% (braked) in kg 1,700 [1,700]

Engine

Cylinders/valves 3/4
Capacity in ccm 1,499
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 103 (140)/4,500-6,500
Engine torque (Nm) at 1/min 220/1,480-4,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 205 [203]
Acceleration 0–100 km/h in s 9.7 [9.7]

Fuel consumption

Urban in l/100 km 6.9 [7.0]
Extra-urban in l/100 km 5.1 [5.1]
Combined in l/100 km 5.8 [5.8]
CO2 combined emissions in g/km 132 [133]
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 225/55 R17 97W
Tyre dimensions rear 225/55 R17 97W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Fuel consumption and CO2 emissions.

  • BMW X1 xDrive20i:
    Fuel consumption in l/100 km (combined): 6.7–6.3
    CO2 emissions in g/km (combined): 152–143

    BMW X1 xDrive25e: temporary peak power 170 kW (231 hp). Duration of peak power increases as the ambient temperature decreases (approx. 5 s at +25°C, up to approx. 40 s at -20°C). This allows acceleration from 0-100 km/h in 6.9 s

    The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

    The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
